Operation Panel (SP 5300/5310)
D255/D256/M281/M282 4-74 SM
4.9 OPERATION PANEL (SP 5300/5310)
4.9.1 OPERATION PANEL
1. Remove the upper cover. (page 4-47)
2. Remove the sheet [A] from back side of the upper cover [B].
3. Remove the seven screws.
 The screws [A] are sems screws. Be careful not to use the wrong screws when
installing the operation panel.
4. Open the bracket [A].
