UP/SP Data Import/Export
D255/D256/M281/M282 5-52 SM
Importing Device Information
Import device information saved on an SD card.
1. Remove the controller cover. (page 4-67)
2. Insert the SD card into the SD Card Slot 2 (lower) [A].
3. Turn the main power ON.
4. Enter SP mode.
5. Select SP5-749-101 (Import/Export: Import).
6. If you want to include the unique information in the imported file, select [Unique].
7. Select [Encryption] -> Enter an encryption key. -> Select [Accept]
8. Press [EXECUTE].
9. Press [OK].
If data export fails, the details of the error can be viewed in the log.
