Engine SP Mode
SM 5-21 D245/D246/D247
Maintenance
2307 [TR Curr Tem Thres]
Specifies the threshold temperature for the reference table of the transfer
current adjustment.
2-307-001
Division 1 *ENG [0 to 99/ 13 / 1 deg / step]
2-307-002
Division 2 *ENG [0 to 99/ 19 / 1 deg / step]
2-307-003
Division 3 *ENG [0 to 99/ 24 / 1 deg / step]
2801 [Deve Initializati]
2-801-001
Init TD Sen Execu ENG [- / - / -]
[Execute]
Executes developer initialization when new PCDU is replaced.
2802 [Developer Mixing]
2-802-001
- ENG [- / - / -]
[Execute]
Initializes the developer and checks the TD sensor output (Vt). The machine
mixes the developer for 2 minutes while reading and displaying the Vt value.
The machine does not initialize the TD sensor output. If the machine has
not been used for a long period, prints may have a dirty background. In a
case like this, use this SP to mix the developer. The message "Completed"
is displayed when the program ends normally.
2803 [Deve Initializati]
2-803-001
Vtref *ENG [0.00 to 9.99 / 2.50 / 0.01 vol / step]
Vtref value at the completion of the initial agent configuration
2-803-002
ID Sensor PWM Val *ENG [0 to 1023 / 0 / 1 /step]
ID sensor PWM value at the time of completion of the initial agent
configuration
