Ricoh MP C2503 Series User Manual

8. Web Image Monitor
This chapter describes frequently used Web Image Monitor functions and operations. For the
information not included in this chapter, see Connecting the Machine/ System Settings on the supplied
CD-ROM or Web Image Monitor Help.
Displaying Top Page
This section explains the Top Page and how to display Web Image Monitor.
• When entering an IPv4 address, do not begin segments with zeros. For example: If the address is
"192.168.001.010", you must enter it as "192.168.1.10".
1. Start your Web browser.
2. Enter "http://(machine's IP address or host name)/" in your Web browser's URL bar.
Top Page of Web Image Monitor appears.
If the machine's host name has been registered on the DNS or WINS server, you can enter it.
When setting SSL, a protocol for encrypted communication, under environment which server
authentication is issued, enter "https://(machine's IP address or host name)/".
Web Image Monitor is divided into the following areas:
1
2
3
5
4
CVD004
1. Menu area
If you select a menu item, its content will be shown.
2. Header area
The dialog box for switching to the user mode and administrator mode appears, and each mode's menu will
be displayed.
The link to Help and dialog box for keyword search appears.
141

Ricoh MP C2503 Series Specifications

General

Functions	Print, Copy, Scan
Print Technology	Laser
Max Print Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Automatic Duplexing	Yes
Paper Output Capacity (Standard)	500 sheets
Processor	600 MHz
Memory (Standard)	1.5 GB
Hard Disk Drive	250 GB
Power Source	220 - 240 V, 50/60 Hz
Print Speed	25 ppm (Black/Color)
Connectivity	USB, Ethernet
Copy Speed	25 ppm (Black/Color)
Zoom	25% - 400%
Scan Speed	Up to 54 ipm (Black/Color)
Paper Input Capacity (Standard)	350 sheets
Paper Size	A3, A4, A5, B4, B5
Paper Weight	60 - 220 g/m²
PDL	PCL6, PostScript 3
Operating System Compatibility	Windows, Mac OS
