Ricoh MP C2503 Series User Manual

Specifying thick paper, thin paper, or OHP transparencies for paper type using the
control panel
• Use A4 or 8
1
/
2
× 11 size OHP transparencies, and specify their size.
• Usually only one side of OHP transparencies can be used for printing. Be sure to load them with the
print side down.
• When printing onto OHP transparencies, remove printed sheets one by one.
1. Display the initial settings screen.
• When using the standard operation panel
Press the [User Tools/Counter] key.
CXX005
• When using the Smart Operation Panel
Press the [Home] key on the top left of the control panel. Flick the screen to the left, and then
press the [User Tools] icon ( ) on the Home screen 4.
2. Press [Tray Paper Settings].
3. Press [Printer Bypass Paper Size], and then specify the paper size.
4. Press [OK].
5. Press [
Next].
6. Press [Paper Type: Bypass Tray].
7. Select the proper items, according to the paper type you want to specify.
• Press [OHP (Transparency)] on the [Paper Type] area when loading OHP transparencies.
• To load thin or thick paper, press [Do not Display] on the [Paper Type] area, and then select
the appropriate paper thickness in the [Paper Thickness] area.
9. Adding Paper and Toner
150

Ricoh MP C2503 Series Specifications

General

Functions	Print, Copy, Scan
Print Technology	Laser
Max Print Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Automatic Duplexing	Yes
Paper Output Capacity (Standard)	500 sheets
Processor	600 MHz
Memory (Standard)	1.5 GB
Hard Disk Drive	250 GB
Power Source	220 - 240 V, 50/60 Hz
Print Speed	25 ppm (Black/Color)
Connectivity	USB, Ethernet
Copy Speed	25 ppm (Black/Color)
Zoom	25% - 400%
Scan Speed	Up to 54 ipm (Black/Color)
Paper Input Capacity (Standard)	350 sheets
Paper Size	A3, A4, A5, B4, B5
Paper Weight	60 - 220 g/m²
PDL	PCL6, PostScript 3
Operating System Compatibility	Windows, Mac OS
