Setting Description Setting value
Phase 2
Security Protocol
Specify the security protocol
to be used in Phase 2.
To apply both encryption and
authentication to sent data,
specify "ESP" or "ESP+AH".
To apply authentication data
only, specify "AH".
(auto setting)
• ESP
• AH
• ESP+AH
Phase 2
Authentication Algorithm
Specify the authentication
algorithm to be used in phase
2.
(auto setting)
• HMAC-MD5-96
• HMAC-SHA1-96
• HMAC-SHA256-128
• HMAC-SHA384-192
• HMAC-SHA512-256
Phase 2
Encryption Algorithm
Permissions
Specify the encryption
algorithm to be used in phase
2.
(auto setting)
• Cleartext (NULL
encryption)
• DES
• 3DES
• AES-128
• AES-192
• AES-256
Phase 2
PFS
Specify whether to activate
PFS. Then, if PFS is activated,
select the Diffie-Hellman
group.
(auto setting)
• Inactive
• 1
• 2
• 14
Phase 2
Validity Period
Specify the time period for
which the SA settings in phase
2 are valid.
Specify a period (in seconds)
from 300 (5min.) to 172800
(48 hrs.).
Configuring IPsec
155

Ricoh MP C2503 Series Specifications

General

Functions	Print, Copy, Scan
Print Technology	Laser
Max Print Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Automatic Duplexing	Yes
Paper Output Capacity (Standard)	500 sheets
Processor	600 MHz
Memory (Standard)	1.5 GB
Hard Disk Drive	250 GB
Power Source	220 - 240 V, 50/60 Hz
Print Speed	25 ppm (Black/Color)
Connectivity	USB, Ethernet
Copy Speed	25 ppm (Black/Color)
Zoom	25% - 400%
Scan Speed	Up to 54 ipm (Black/Color)
Paper Input Capacity (Standard)	350 sheets
Paper Size	A3, A4, A5, B4, B5
Paper Weight	60 - 220 g/m²
PDL	PCL6, PostScript 3
Operating System Compatibility	Windows, Mac OS
