4. Paper guides
When loading paper in the bypass tray, align the paper guides flush against the paper.
5. Extender
Pull this extender out when loading sheets larger than A4 , 8
1
/
2
× 11 in the bypass tray.
6. Lower right cover
Open this cover when a paper jam occurs.
7. Right cover
Open this cover when a paper jam occurs.
Rear and left view
1. Vents
Prevent overheating.
