5. [Check Status] key
Press to check the machine's system status, operational status of each function, and current jobs. You can also
display the job history and the machine's maintenance information.
6. Data In indicator (facsimile and printer mode)
Flashes when the machine is receiving print jobs or LAN-Fax documents from a computer. See Fax and Print.
7. Fax indicator
Indicates the status of the fax functions. Flashes during data transmission and reception. Stays lit when
receiving a fax via Confidential or Substitute Reception.
8. [Menu] key
Displays the menu screen while Screen Features are enabled or applications available only on the Smart
Operation Panel are used.
9. [Return] key
Press this key to return to the previous screen while Screen Features are enabled or applications available only
on the Smart Operation Panel are used.
10. Media access lamp
Lights up when a memory storage device is inserted in the media slot.
11. Media slots
Use to insert an SD card or a USB flash memory device.
Guide to the Names and Functions of the Machine's Control Panel (When Using the Smart Operation Panel)
45

Ricoh MP C2503 Series Specifications

General

Functions	Print, Copy, Scan
Print Technology	Laser
Max Print Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Automatic Duplexing	Yes
Paper Output Capacity (Standard)	500 sheets
Processor	600 MHz
Memory (Standard)	1.5 GB
Hard Disk Drive	250 GB
Power Source	220 - 240 V, 50/60 Hz
Print Speed	25 ppm (Black/Color)
Connectivity	USB, Ethernet
Copy Speed	25 ppm (Black/Color)
Zoom	25% - 400%
Scan Speed	Up to 54 ipm (Black/Color)
Paper Input Capacity (Standard)	350 sheets
Paper Size	A3, A4, A5, B4, B5
Paper Weight	60 - 220 g/m²
PDL	PCL6, PostScript 3
Operating System Compatibility	Windows, Mac OS
