Ricoh RT5120 - Return Solenoid

1.Replacement and Adjustment
40
3. Remove the screws to detach the float fan shutter solenoid.
Return Solenoid
1. Remove the float/separation/return fan bracket (Float/Separation/Return Fan Bracket)
The position of the return solenoid [A] (attached to the float/separation/return fan duct)
