Ricoh RT5120 - Vertical Transport Entrance Contact Sensor; Vertical Transport Entrance Sensor

1.Replacement and Adjustment
97
Vertical Transport Entrance Contact Sensor / Vertical Transport Entrance Sensor
1. Remove the vertical feed unit (Vertical Feed Unit)
2. Remove the shoulder screw [A] on the right side of the vertical feed unit.
3. Remove the right cover [A] from the vertical feed unit ( x5).
