1.Replacement and Adjustment
10
Top Cover Interlock Switch
1. Remove the rear left cover. (Rear Left Cover)
2. Open the clamps on the left side of the main board to loosen the white/black harness [A], which
runs to the interlock switch.
Main board location [A]
