7 TROUBLE SHOOTING
RIELE BERLIN Photometer 5010 / V4 7.2 17.09.2003
23 overflow at Kinetic check measuring solution
24 overflow at Kinetic check measuring solution
25 overflow at Kinetic check measuring solution
26 overflow at Kinetic check measuring solution
27 overflow at Kinetic check measuring solution
28 overflow at Kinetic check measuring solution
29 Input of deltas or time per delta wrong restart method
30 - not occupied -
31 communication: wrong data format check data sent at the communication partner formally
32 communication: sent data not plausible / not
interpretable
check data sent at the communication partner as
regards content
33 communication: mentioned module does not answer in
a certain time
check interconnecting cable; check mentioned module
34 communication: overflow send/receive buffer reduce amount of data at the communication partner
35 Remote control: wrong method number external software problem
36 Remote control: unknown command external software problem
37 Remote control: wrong data format external software problem
38 timeout at reception from modul 1 switch off/on device
39 check sum error at reception from modul 1 switch off/on device
40 timeout at reception from modul 2 switch off/on device
41 check sum error at reception from modul 2 switch off/on device
42 NAK at reception from modul 2 switch off/on device
43 NAK at reception from modul 1 switch off/on device
44 error at pump calibration
the pump tube is not clamped;
no liquid was aspirated;
to much liquid was aspirated when calibrating;
the power of the pump is to small;
the motor does not rotate or stops;
connectors of tubes leak;
bubble detector works incorrect;
the inlet tube is blocked;
the inlet tube has a change in color
clamp pump tube;
control volume of aspiration;
control connectors of tubes;
the plug of the bubble detector has a bad contact;
the cable of the bubble detector has a bad contact;
adjust bubble detector (OM chapter 8.2.2);
replace inlet tube (OM chapter 9.7)
45 error at sipping solution
the pump tube is not clamped;
no liquid was aspirated;
the power of the pump is to small;
the motor does not rotate or stops;
connectors of tubes leak;
bubble detector works incorrect;
the inlet tube is blocked;
the inlet tube has a change in color
clamp pump tube;
control volume of aspiration;
control connectors of tubes;
do a calibration of peristaltic pump (OM chapter 5.7);
the plug of the bubble detector has a bad contact;
the cable of the bubble detector has a bad contact;
adjust bubble detector (OM chapter 8.2.2);
replace inlet tube (OM chapter 9.7)
46 filter position outside tolerance
47 + 12 V
DC
of halogenlamp out of range check voltage (SM chapter 4.40)
To Next Page
