4.22 STANDARD CUVETTE ADAPTOR ID 1704800001
RIELE BERLIN Photometer 5010 / V4 4.22.1 22.08.2003
Function Description
The standard cuvette adaptor is used for disposable cuvettes.
The standard cuvette adaptor consists of:
• Plastic adapter
• Heating unit
• Plug
• Potentiometer for factory calibration
Location
Optical unit
Replacement
Loosen clamp screw, remove adaptor.
Installation
For installation proceed in reverse order.
After installation of a new cuvette adaptor or a change e.g. from the flow-through cuvette adaptor to the
standard cuvette adaptor a dark level adjustment with [MODE] [MODE] [1] is recommended.
holding spring for disp. cuvette
ID 1707159001
