4.20 BUBBLE DETECTOR WITH PLUG ID 1706870001
RIELE BERLIN Photometer 5010 / V4 4.20.1 18.09.2003
Function Description
The bubble detector controls the rotations of the peristaltic pump means the aspirated volume.
Location
Optical unit
Replacement
Disconnect plug of detector.
Installation
For installation proceed in reverse order.
See also exploded view, chapter „Dismantling“
