4.40 MOTHER BOARD RR-115 ID 5010-115
RIELE BERLIN Photometer 5010 / V4 4.40.12 22.09.2003
Installation instruction
In case of changing the mother board following items have to be done after switching on the device:
1. Check the contrast of LCD.
See Service Manual chapter 4.40 – Contrast of LCD.
2. Check the voltage 12 V
DC
of halogen lamp. The voltage was preadjusted at factory.
See Service Manual chapter 4.40 – Voltage 12 V
DC
of halogen lamp.
3. Check voltages + 12 V
DC
, - 12 V
DC
, + 5 V
DC
and + 3 V
DC
(battery power).
See Service Manual chapter 4.40 – Voltages.
4. Perform the adjustment of amplifier stage.
See Service Manual chapter 4.40 – Adjustment of amplifier stage.
5. The display of Photometer 5010 shows:
6. The serial number can be set by applying the service tool S4.
See Service Manual chapter 3.4 - S4 Serial number.
7. The assignment of filter positions has to be done if additional filters has been built in
(e.g. 670 nm). Apply the tool S6.
See Service Manual chapter 3.4 - S6 Filter select.
8. Do a setting of temperature values by performing the calibration procedure of Photometer 5010 /
Subject: Cuvette temperature.
See Service Manual chapter 9.1
9. Do a setting of “attribut of PCB layout“ by applying the service tool S13:
Software applications may be dependent on this attribut.
See Service Manual chapter 3.4 - S13 Attribut of PCB layout.
10. Do a “patients data initialization“ by applying the service tool S14:
Attention!
The memory of patients data mangement is cleared completely.
In case of a migration to operating system version 3.5 the operation has to be done.
11. Define the laboratory name by applying the utility U18:
The name of the laboratory can be stored permanently.
In case of a migration to operating system version 3.5 the operation has to be done.
12. Define the user names by applying the utility U19:
The names of maximum five users can be stored permanently.
In case of a migration to operating system version 3.5 the operation has to be done.
13. Do a dark level adjustment by applying utility U1 in combination with flow-through system.
See OM chapter 8.2.1 - Dark level adjustment.
The utility is working specifically to the current adaptor. An adjustment of the standard cuvette adaptor
should be done later on.
14. Do a media test by applying utility U2.
See OM chapter 8.2.2 - Adjustment of bubble detector.
15. Perform a pump calibration by applying MODE FUNCTION - Pump utilities - Calibration.
See OM chapter 5.7 - Pump calibration.
16. Switch off Photometer 5010. Change the cuvette adaptor. Switch on Photometer 5010
17. Do a dark level adjustment by applying utility U1 in combination with standard cuvette adapter.
See OM chapter 8.2.1 - Dark level adjustment.
18. Control the settings by applying utility U12.
See OM chapter 8.2.12 - Printing device configuration.
