4.3 AC / DC POWER SUPPLY ID 5010-016
RIELE BERLIN Photometer 5010 / V4 4.3.1 11.05.2004
Function Description
The AC / DC power supply is designed for producing following voltages:
• V1: + 5 V
DC
/ 7 A
• V2: + 15 V
DC
/ 3 A
• V3: - 15 V
DC
/ 1 A
Location
Basis plate of Photometer 5010
Replacement
The Photometer 5010 has to be opened. The top case has to be separated from the bottom case.
Installation
For installation proceed in reverse order.
See also exploded view, chapter „Dismantling“
Terminal block
