Sample Plates
92 SmartLab: Automated Multipurpose X-ray Diffractometer
Installing and removing wafer sample plates
To mount a wafer sample plate to a sample spacer, align the sections indicated
by the arrows in the figure below, then turn the sample plate clockwise to secure
it in place.
The wafer sample plate can be removed by turning it counterclockwise.
Installing/removing the wafer sample plate
See Installing and removing sample spacers for information on direct mounting (removing)
a wafer sample plate to (from) an attachment.
