SmartLab: Automated Multipurpose X-ray Diffractometer 9
Names of Parts
General view of SmartLab
(Left: 2080A211/2080B211/2080A411/2080B411, Right: 2080B212)
1. Rotary pump
Pump for maintaining the vacuum in the x-ray generator.
(2080A211/2080A411）
2. Control PC PC used to control SmartLab.
Main unit
Front view of SmartLab
(Left: 2080A211/2080B211/2080A411/2080B411, Right: 2080B212)
3.
1.
5.
4.
4.
3.
5.
2.
1.
2.
1.
2.
