Names of Parts
16 SmartLab: Automated Multipurpose X-ray Diffractometer
Detector mounting bracket
Detector mounting bracket
1. Base
Used to secure the detector in
place.
2. Detector adaptor Used to attach the detector.
Sample stage and attachments
Sample stage and attachments
1. Sample stage Sample attachment unit.
2. Attachment
Attachment to be mounted to the
sample stage.
3. Sample plate
Plate on which sample holder or
sample is placed.
2. 3. 1.
1.
2.
