Receiving optics unit CALSA (option: 2680K201)
SmartLab: Automated Multipurpose X-ray Diffractometer 61
Receiving optics unit CALSA (option: 2680K201)
CALSA is a multi-crystal analyzer, which is used by installing onto the theta_d
arm. It achieves the ultrahigh resolution of the X-ray diffraction beam from a
sample.
The positions of the analyzer crystals and detector can be aligned from
SmartLab Guidance.
CALSA
1 Remove all the units installed on the theta_d arm.
2 Attach CALSA on therail of the theta_d arm and set the installation
position to 200 mm. The position can be read from the scale on the
theta_d arm.
To Next Page
