Optics
36 SmartLab: Automated Multipurpose X-ray Diffractometer
4-bounce monochromator (option)
This optical device produces a monochromatized x-ray beam using two
2-bounce channel cut crystals.
Fine alignment of the channel cut crystals can be performed from SmartLab
Guidance.
4-bounce monochromator
1 Attach the 4-bounce monochromator to the CBO unit by sliding it
down from the top section of the CBO unit. Secure it in place with the
Allen wrench provided.
To Next Page
