Incident optics unit (standard incident optics unit)
SmartLab: Automated Multipurpose X-ray Diffractometer 37
2 Connect the cable to the MONO/ADPT connector on the incident
connector box.
Table 4-bounce monochromators
Crystal
Diffraction
plane
Abbreviation Illustration
Ge
(option: 2680B211)
220 Ge(220)x4
Ge
(option: 2680B212)
440 Ge(440)x4
The type of installed crystal can be identified from SmartLab Guidance
