Optics
38 SmartLab: Automated Multipurpose X-ray Diffractometer
CBO-f unit (option: 2220C301)
Converges the parallel beam in the longitudinal direction onto the sample. The
optical device is used for the measurements of micro amount of a sample and of
micro area.
Fine alignment of the CBO-f unit is performed from SmartLab Guidance.
CBO-f unit
1 Install the CBO-f unit to the theta_s arm from the top, and secure it in
place with the Allen wrench provided.
