RIGOL Chapter 2 Command System
2-98 MSO1000Z/DS1000Z Programming Guide
:MATH:FFT:HCENter
Syntax
:MATH:FFT:HCENter <cent>
:MATH:FFT:HCENter?
Description
Set or query the center frequency of the FFT operation result, namely the frequency
relative to the horizontal center of the screen. The default unit is Hz.
Parameter
Name
Type
Range
Default
<cent>
Real
Refer to Explanation
5MHz
Explanation
 When the FFT mode is set to TRACe, the range of <cent> is from 0 to (0.4 x FFT
sample rate). Wherein, FFT sample rate equals to screen sample rate, that is,
100/horizontal timebase.
When the FFT mode is set to MEMory, the range of <cent> is from 0 to (0.5 x FFT
sample rate). Wherein, FFT sample rate equals to memory sample rate
(:ACQuire:SRATe?).
 Step = Horizontal Scale of the FFT operation result/50.
Return
Format
The query returns the current center frequency in scientific notation.
Example
:MATH:FFT:HCENter 10000000 /*Set the center frequency of the FFT operation result
to 10MHz*/
:MATH:FFT:HCENter? /*The query returns 1.000000e+07*/
Related
Commands
:MATH:OPERator
:MATH:FFT:MODE
:TIMebase[:MAIN]:SCALe
:MATH:FFT:HSCale
:MATH:FFT:MODE
Syntax
:MATH:FFT:MODE <mode>
:MATH:FFT:MODE?
Description
Set or query the FFT mode.
Parameter
Name
Type
Range
Default
<mode>
Discrete
{TRACe|MEMory}
TRACe
Explanation
 TRACe: denotes that the data source of the FFT operation is the data of the
waveform displayed on the screen.
 MEMory: denotes that the data source of the FFT operation is the data of the
waveform in the memory.
Return
Format
The query returns TRAC or MEM.
Example
:MATH:FFT:MODE TRACe /*Set the FFT mode to TRACe*/
:MATH:FFT:MODE? /* The query returns TRAC*/

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
