Rigol DS1074Z Plus Programming Guide

RIGOL Chapter 2 Command System
2-102 MSO1000Z/DS1000Z Programming Guide
:MATH:OPTion:END
Syntax
:MATH:OPTion:END <end>
:MATH:OPTion:END?
Description
Set or query the end point of the waveform math operation.
Parameter
Name
Type
Range
Default
<end>
Discrete
(Start point currently set+1) to 1199
1199
Explanation
 This command is invalid for the FFT operation. Sending this command will modify the
end points of all the operations (except FFT).
 The source selected is equally divided into 1200 parts horizontally, in which the
leftmost is 0 and the rightmost is 1199.
Return
Format
The query returns an integer.
Example
:MATH:OPTion:END 200 /*Set the waveform end point to 200*/
:MATH:OPTion:END? /*The query returns 200*/
Related
Command
:MATH:OPTion:STARt
:MATH:OPTion:INVert
Syntax
:MATH:OPTion:INVert <bool>
:MATH:OPTion:INVert?
Description
Enable or disable the inverted display mode of the operation result, or query the inverted
display mode status of the operation result.
Parameter
Name
Type
Range
Default
<bool>
Bool
{{1|ON}|{0|OFF}}
0|OFF
Explanation
 This command is invalid for the FFT operation. Sending this command will modify
the inverted display mode status of all the operations (except FFT).
 This command has the same function as the :MATH:INVert command.
Return
Format
The query returns 1 or 0.
Example
:MATH:OPTion:INVert ON /*Enable the inverted display mode*/
:MATH:OPTion:INVert? /*The query returns 1*/

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
