Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-107
:MASK Commands
The :MASK commands are used to set and query the pass/fail test parameters.
Command List:
 :MASK:ENABle
 :MASK:SOURce
 :MASK:OPERate
 :MASK:MDISplay
 :MASK:SOOutput
 :MASK:OUTPut
 :MASK:X
 :MASK:Y
 :MASK:CREate
 :MASK:PASSed?
 :MASK:FAILed?
 :MASK:TOTal?
 :MASK:RESet
:MASK:ENABle
Syntax
:MASK:ENABle <bool>
:MASK:ENABle?
Description
Enable or disable the pass/fail test or query the status of the past/fail test.
Parameter
Name
Type
Range
Default
<bool>
Bool
{{1|ON}|{0|OFF}}
0|OFF
Explanation
The pass/fail test is invalid in the following conditions: the horizontal timebase is XY or
ROLL, in the slow sweep mode (namely when the horizontal timebase is YT, the
horizontal timebase is set to 200ms/div or slower) as well as during waveform record.
Return
Format
The query returns 1 or 0.
Example
:MASK:ENABle ON /*Enable the pass/fail test*/
:MASK:ENABle? /*The query returns 1*/

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
