:MEASure:SETup:MIN
Syntax
:MEASure:SETup:MIN <value>
:MEASure:SETup:MIN?
Description
Set or query the lower limit of the threshold (expressed in the percentage of amplitude) in
time, delay, and phase measurements.
Parameter
Name
Type
Range
Default
<value>
Integer
5 to 93
10
Explanation
 The upper limit, middle point, and lower limit of the threshold (expressed in the
percentage of amplitude) are used to define the time, delay, and phase parameters.
Setting these values will affect the measurement results of the time, delay, and phase
parameters.
 Setting the lower limit greater than the middle point will automatically increase the
middle point to keep it greater than the lower limit.
Return
Format
The query returns an integer between 5 and 93.
Example
:MEASure:SETup:MIN 53 /*Set the lower limit of the threshold to 53%*/
:MEASure:SETup:MIN? /*The query returns 53*/
Related
Commands
:MEASure:SETup:MAX
:MEASure:SETup:MID
:MEASure:ITEM
:MEASure:SETup:PSA
Syntax
:MEASure:SETup:PSA <source>
:MEASure:SETup:PSA?
Description
Set or query source A of Phase 1→2 and Phase 1→2 measurements.
Parameter
Name
Type
Range
Default
<source>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|
D9|D10|D11|D12|D13|D14|D15|
CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:MEASure:SETup:PSA CHANnel1 /*Set source A of phase measurement to CH1*/
:MEASure:SETup:PSA? /*The query returns CHAN1*/
Related
Command
:MEASure:ITEM

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
