Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-83
:LA:AUTosort
Syntax
:LA:AUTosort <n>
Description
Set the auto ordering mode of the waveforms of the channels turned on on the screen.
Parameter
Name
Type
Range
Default
<n>
Discrete
{0|1}
1
Explanation
 <n> = 0: waveforms on the screen are D15 to D0 from top to bottom
 <n> = 1: waveforms on the screen are D0 to D15 from top to bottom
:LA:DIGital<n>:DISPlay
Syntax
:LA:DIGital<n>:DISPlay <bool>
:LA:DIGital<n>:DISPlay?
Description
Turn on or off the specified digital channel, or query the status of the specified digital
channel.
Parameter
Name
Type
Range
Default
<n>
Integer
0 to 15
--
<bool>
Bool
{{1|ON}|{0|OFF}}
D0 to D7: 1|ON
D8 to D15: 0|OFF
Explanation
You can set the channels currently turned on as the active channel using the :LA:ACTive
command.
Return
Format
The query returns 1 or 0.
Example
:LA:DIGital3:DISPlay ON /*Turn D3 on*/
:LA:DIGital3:DISPlay? /*The query returns 1*/

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
