RIGOL Chapter 2 Command System
2-134 MSO1000Z/DS1000Z Programming Guide
[:SOURce[<n>]]:FUNCtion:RAMP:SYMMetry
Syntax
[:SOURce[<n>]]:FUNCtion:RAMP:SYMMetry <val>
[:SOURce[<n>]]:FUNCtion:RAMP:SYMMetry?
Description
Set or query the ramp symmetry (the percentage that the rising period takes up in the
whole period) of the specified source channel.
Parameter
Name
Type
Range
Default
[<n>]
Discrete
{1|2}
If omitted, the operation is
performed on source 1 by
default
<val>
Real
0 to 100
10
Return
Format
The query returns the symmetry in scientific notation, such as 5.000000e+01.
Example
:FUNCtion:RAMP:SYMMetry 50 /*Set the ramp symmetry of source 1 to 50%*/
:FUNCtion:RAMP:SYMMetry? /*The query returns 5.000000e+01*/
Related
Command
[:SOURce[<n>]]:FUNCtion[:SHAPe]
[:SOURce[<n>]]:VOLTage[:LEVel][:IMMediate][:AMPLitude]
Syntax
[:SOURce[<n>]]:VOLTage[:LEVel][:IMMediate][:AMPLitude] <Amplitude>
[:SOURce[<n>]]:VOLTage[:LEVel][:IMMediate][:AMPLitude]?
Description
Set or query the output amplitude of the specified source channel. The default unit is Vpp.
Parameter
Name
Type
Range
Default
[<n>]
Discrete
{1|2}
If omitted, the operation is
performed on source 1 by
default
<Ampliude>
Real
Related to the output
impedance
HighZ: 20mVpp to 5Vpp
50Ω: 10mVpp to 2.5Vpp
5Vpp
Explanation
You can use the [:SOURce[<n>]]:OUTPut[<n>]:IMPedance command to set the output
impedance.
Return
Format
The query returns the amplitude in scientific notation, such as 1.0000000e+00.
Example
:VOLTage 2 /*Set the output amplitude of source 1 to 2V*/
:VOLTage? /*The query returns 2.0000000e+00*/

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
