Rigol DS1074Z Plus Programming Guide

RIGOL Chapter 2 Command System
2-62 MSO1000Z/DS1000Z Programming Guide
:DISPlay Commands
The :DISPlay commands can be used to set the waveform display mode, persistence time, waveform
intensity, screen grid type and grid brightness.
Command List:
 :DISPlay:CLEar
 :DISPlay:DATA?
 :DISPlay:TYPE
 :DISPlay:GRADing:TIME
 :DISPlay:WBRightness
 :DISPlay:GRID
 :DISPlay:GBRightness
:DISPlay:CLEar
Syntax
:DISPlay:CLEar
Description
Clear all the waveforms on the screen.
Explanation
 If the oscilloscope is in the RUN state, waveform will still be displayed.
 This command is equivalent to pressing the CLEAR key at the front panel. Sending
the :CLEar command can also clear all the waveforms on the screen.
Related
Command
:RUN

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
