Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-61
:DECoder<n>:PARallel:PLOT
Syntax
:DECoder<n>:PARallel:PLOT <bool>
:DECoder<n>:PARallel:PLOT?
Description
Turn on or off the curve function of parallel decoding, or query the status of the curve
function of parallel decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<bool>
Bool
{{1|ON}|{0|OFF}}
0|OFF
Explanation
When this function is turned on, the variation trend of the bus data is displayed in vector
diagram form.
Return
Format
The query returns 1 or 0.
Example
:DECoder1:PARallel:PLOT ON /*Turn on the curve function*/
:DECoder1:PARallel:PLOT? /*The query returns 1*/

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
