Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-105
:MATH:OPTion:THReshold2
Syntax
:MATH:OPTion:THReshold2 <thre>
:MATH:OPTion:THReshold2?
Description
Set or query the threshold level of source B in logic operations. The default unit is V.
Parameter
Name
Type
Range
Default
<thre>
Real
(-4 x VerticalScale - VerticalOffset) to
(4 x VerticalScale - VerticalOffset)
0.00V
Explanation
 This command is only applicable to A&&B, A||B, and A^B logic operations of which
source B is an analog channel.
 VerticalScale refers to the vertical scale of source B
VeticalOffset refers to the vertical offset of source B
The step is VerticalScale/50
Return
Format
The query returns the threshold level in scientific notation.
Example
:MATH:OPTion:THReshold2 0.5 /*Set the threshold level of source B in logic
operations to 0.5V*/
:MATH:OPTion:THReshold2? /*The query returns 5.000000e-01*/
Related
Commands
:CHANnel<n>:SCALe
:CHANnel<n>:OFFSet
:MATH:LSOUrce2
:MATH:OPTion:FX:SOURce1
Syntax
:MATH:OPTion:FX:SOURce1 <src>
:MATH:OPTion:FX:SOURce1?
Description
Set or query source A of the inner layer operation of compound operation.
Parameter
Name
Type
Range
Default
<src>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:MATH:OPTion:FX:SOURce1 CHANnel1 /*Set source A of the inner layer operation of
compound operation to CH1*/
:MATH:OPTion:FX:SOURce1? /*The query returns CHAN1*/

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
