RIGOL Chapter 2 Command System
2-142 MSO1000Z/DS1000Z Programming Guide
:STORage Commands
The :STORage commands are used to set the related parameters when storing images.
Command List:
 :STORage:IMAGe:TYPE
 :STORage:IMAGe:INVERT
 :STORage:IMAGe:COLor
:STORage:IMAGe:TYPE
Syntax
:STORage:IMAGe:TYPE <type>
:STORage:IMAGe:TYPE?
Description
Set or query the image type when storing images.
Parameter
Name
Type
Range
Default
<type>
Discrete
{PNG|BMP8|BMP24|JPEG|TIFF}
PNG
Return
Format
The query returns PNG, BMP8, BMP24, JPEG, or TIFF.
Example
:STORage:IMAGe:TYPE PNG /*Set the image type when storing images to PNG*/
:STORage:IMAGe:TYPE? /*The query returns PNG*/
:STORage:IMAGe:INVERT
Syntax
:STORage:IMAGe:INVERT <bool>
:STORage:IMAGe:INVERT?
Description
Turn on or off the invert function when storing images; or query the status of the invert
function.
Parameter
Name
Type
Range
Default
<bool>
Bool
{{1|ON}|{0|OFF}}
0|OFF
Return
Format
The query returns ON or OFF.
Example
:STORage:IMAGe:INVERT ON /*Turn on the invert function when storing images*/
:STORage:IMAGe:INVERT? /*The query returns ON*/

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
