Rigol DS1074Z Plus Programming Guide

RIGOL Chapter 2 Command System
2-128 MSO1000Z/DS1000Z Programming Guide
:REFerence<n>:VOFFset
Syntax
:REFerence<n>:VOFFset <offset>
:REFerence<n>:VOFFset?
Description
Set or query the vertical offset of the specified reference channel. The unit is the
same as the unit of the source.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4|5|6|7|8|9|10}
--
<offset>
Real
(-10 x RefVerticalScale) to (10 x RefVerticalScale)
0
Explanation
RefVerticalScale refers to the vertical scale of the reference channel.
Return Format
The query returns the vertical offset in scientific notation.
Example
:REFerence1:VOFFset 0.5 /*Set the vertical offset of reference channel 1 to
500mV*/
:REFerence1:VOFFset? /*The query returns 5.000000e-01*/
Related
Commands
:REFerence<n>:SOURce
:REFerence<n>:VSCale
:REFerence<n>:RESet
Syntax
:REFerence<n>:RESet
Description
Reset the vertical scale and vertical offset of the specified reference channel to their
default values.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4|5|6|7|8|9|10}
--
:REFerence<n>:CURRent
Syntax
:REFerence<n>:CURRent
Description
Select the current reference channel.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4|5|6|7|8|9|10}
1
Explanation
Only reference channels currently turned on can be selected as the current
reference channel.
Related
Command
:REFerence<n>:ENABle

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
