RIGOL Chapter 2 Command System
2-192 MSO1000Z/DS1000Z Programming Guide
:TRIGger:DELay
Command List:
 :TRIGger:DELay:SA
 :TRIGger:DELay:SLOPA
 :TRIGger:DELay:SB
 :TRIGger:DELay:SLOPB
 :TRIGger:DELay:TYPe
 :TRIGger:DELay:TUPPer
 :TRIGger:DELay:TLOWer
:TRIGger:DELay:SA
Syntax
:TRIGger:DELay:SA <Source>
:TRIGger:DELay:SA?
Description
Set or query the trigger source A in delay trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:TRIGger:DELay:SA CHANnel2 /*Set the trigger source A to CH2*/
:TRIGger:DELay:SA? /*The query returns CHAN2*/
:TRIGger:DELay:SLOPA
Syntax
:TRIGger:DELay:SLOPA <slope>
:TRIGger:DELay:SLOPA?
Description
Set or query the edge type of edge A in delay trigger.
Parameter
Name
Type
Range
Default
<slope>
Discrete
{POSitive|NEGative}
POSitive
Return
Format
The query returns POS or NEG.
Example
:TRIGger:DELay:SLOPA NEGative /*Set the edge type of edge A to falling edge*/
:TRIGger:DELay:SLOPA? /*The query returns NEG*/
