RIGOL Chapter 2 Command System
2-16 MSO1000Z/DS1000Z Programming Guide
:CURSor Commands
The :CURSor commands are used to measure the X-axis value (such as time) and Y-axis value (such as
voltage) of the waveform displayed on the screen.
Command List:
 :CURSor:MODE
 :CURSor:MANual
 :CURSor:TRACk
 :CURSor:AUTO
 :CURSor:XY
:CURSor:MODE
Syntax
:CURSor:MODE <mode>
:CURSor:MODE?
Description
Set or query the cursor measurement mode.
Parameter
Name
Type
Range
Default
<mode>
Discrete
{OFF|MANual|TRACk|AUTO|XY}
OFF
Explanation
 OFF: disable the cursor measurement function.
 MANual: enable the manual cursor measurement mode.
 TRACk: enable the track cursor measurement mode.
 AUTO: enable the auto cursor measurement mode.
 XY: enable the XY cursor measurement mode. This mode is valid only when the
horizontal timebase mode is XY.
Return
Format
The query returns OFF, MAN, TRAC, AUTO, or XY.
Example
:CURSor:MODE MANual /*Enable the manual cursor measurement mode*/
:CURSor:MODE? /*The query returns MAN*/
Related
Commands
:CURSor:MANual
:CURSor:TRACk
:CURSor:XY
:TIMebase:MODE

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
