Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-99
:MATH:FILTer:TYPE
Syntax
:MATH:FILTer:TYPE <type>
:MATH:FILTer:TYPE?
Description
Set or query the filter type.
Parameter
Name
Type
Range
Default
<type>
Discrete
{LPASs|HPASs|BPASs|BSTOP}
LPASs
Explanation
 MSO1000Z/DS1000Z provides 4 types of filters (Low Pass Filter, High Pass Filter,
Band Pass Filter, and Band Stop Filter). Setting the bandwidth can filter the
specified frequencies. You can send the :MATH:FFT:SOURce command to set or
query the source of the filter.
 LPASs: low pass, which indicates that only the signals whose frequencies are lower
than the current cutoff frequency (ωc1) can pass the filter.
 HPASs: high pass, which indicates that only the signals whose frequencies are
greater than the current cutoff frequency (ωc1) can pass the filter.
 BPASs: band pass, which indicates that only the signals whose frequencies are
greater than current cutoff frequency 1 (ωc1) and lower than current cutoff
frequency 2 (ωc2) can pass the filter.
Note: Cutoff frequency 1 (ωc1) must be lower than cutoff frequency 2 (ωc2).
 BSTOP: band stop, which indicates that only the signals whose frequencies are
lower than current cutoff frequency 1 (ωc1) or greater than current cutoff
frequency 2 (ωc2) can pass the filter.
Note: Cutoff frequency 1 (ωc1) must be lower than cutoff frequency 2 (ωc2).
Return
Format
The query returns LPAS, HPAS, BPAS, or BSTOP.
Example
:MATH:FILTer:TYPE LPASs /*Set the filter type to low pass*/
:MATH:FILTer:TYPE? /*The query returns LPAS*/
Related
Commands
:MATH:FILTer:W1
:MATH:FILTer:W2
