Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-73
:FUNCtion:WRECord:OPERate
Syntax
:FUNCtion:WRECord:OPERate <opt>
:FUNCtion:WRECord:OPERate?
Description
Start or stop the waveform recording, or query the status of the waveform recording.
Parameter
Name
Type
Range
Default
<opt>
Discrete
{RUN|STOP}
--
Explanation
Before sending this command, send the :FUNCtion:WRECord:ENABle command to turn
on the waveform recording function. Otherwise, this command is invalid.
Return
Format
The query returns RUN or STOP.
Example
:FUNCtion:WRECord:OPERate RUN /*Start the waveform recording*/
:FUNCtion:WRECord:OPERate? /*The query returns RUN if the recording is in
progress and returns STOP if the recording has
already finished*/
:FUNCtion:WRECord:ENABle
Syntax
:FUNCtion:WRECord:ENABle <bool>
:FUNCtion:WRECord:ENABle?
Description
Turn on or off the waveform recording function, or query the status of the waveform
recording function.
Parameter
Name
Type
Range
Default
<bool>
Bool
{{1|ON}|{0|OFF}}
0|OFF
Explanation
 The waveform recording function can only be enabled when the horizontal timebase
mode is "YT" and the horizontal timebase is lower than 200ms.
 After turning on the waveform recording function, RUN/STOP can be used to start
or stop the waveform recording. At this point, you can send
the :FUNCtion:WRECord:OPERate command to start the recording.
Return
Format
The query returns 1 or 0.
Example
:FUNCtion:WRECord:ENABle 1 /*Turn on the waveform recording function*/
:FUNCtion:WRECord:ENABle? /*The query returns 1*/
