Rigol DS1074Z Plus Programming Guide

RIGOL Chapter 2 Command System
2-50 MSO1000Z/DS1000Z Programming Guide
:DECoder<n>:SPI
The :DECoder<n>:SPI commands are used to set the SPI decoding parameters.
Command List:
 :DECoder<n>:SPI:CLK
 :DECoder<n>:SPI:MISO
 :DECoder<n>:SPI:MOSI
 :DECoder<n>:SPI:CS
 :DECoder<n>:SPI:SELect
 :DECoder<n>:SPI:MODE
 :DECoder<n>:SPI:TIMeout
 :DECoder<n>:SPI:POLarity
 :DECoder<n>:SPI:EDGE
 :DECoder<n>:SPI:ENDian
 :DECoder<n>:SPI:WIDTh
:DECoder<n>:SPI:CLK
Syntax
:DECoder<n>:SPI:CLK <clk>
:DECoder<n>:SPI:CLK?
Description
Set or query the signal source of the clock channel in SPI decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<clk>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|
D9|D10|D11|D12|D13|D14|D15|
CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:DECoder1:SPI:CLK D0 /*Set the signal source of the clock channel in SPI decoding
to D0*/
:DECoder1:SPI:CLK? /*The query returns D0*/

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
