RIGOL Chapter 2 Command System
2-54 MSO1000Z/DS1000Z Programming Guide
:DECoder<n>:SPI:POLarity
Syntax
:DECoder<n>:SPI:POLarity <pol>
:DECoder<n>:SPI:POLarity?
Description
Set or query the polarity of the SDA data line in SPI decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<pol>
Discrete
{NEGative|POSitive}
POSitive
Explanation
 NEGative: . The low level is 1.
 POSitive: . The high level is 1.
Return
Format
The query returns NEG or POS.
Example
:DECoder1:SPI:POLarity NEG ative /*Set the polarity of the SDA data line in SPI
decoding to negative*/
:DECoder1:SPI:POLarity? /*The query returns NEG*/
:DECoder<n>:SPI:EDGE
Syntax
:DECoder<n>:SPI:EDGE <edge>
:DECoder<n>:SPI:EDGE?
Description
Set or query the clock type when the instrument samples the data line in SPI decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<edge>
Discrete
{RISE|FALL}
RISE
Return
Format
The query returns RISE or FALL.
Example
:DECoder1:SPI:EDGE FALL /*Set the instrument to sample data on the falling edge
of the clock in SPI decoding*/
:DECoder1:SPI:EDGE? /*The query returns FALL*/
:DECoder<n>:SPI:ENDian
Syntax
:DECoder<n>:SPI:ENDian <endian>
:DECoder<n>:SPI:ENDian?
Description
Set or query the endian of the SPI decoding data.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<endian>
Discrete
{LSB|MSB}
MSB
Return
Format
The query returns LSB or MSB.
Example
:DECoder1:SPI:ENDian MSB /*Set the data endian of the SPI decoding to MSB*/
:DECoder1:SPI:ENDian? /*The query returns MSB*/

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
