Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-149
[:TRACe[<n>]]:DATA:DAC16
Syntax
[:TRACe[<n>]]:DATA:DAC16 volatile,<flag>,<binary_block_data>
Description
Download binary data block to the volatile memory of the specified signal source.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
1
<flag>
Discrete
{END}
--
<binary_block_data>
Refer to Explanation
Explanation
 This command consists of two parts: the command string
([:TRACe[<n>]]:DATA:DAC16 volatile,<flag>,) and the binary data
(<binary_block_data>).
 <flag> denotes the data transmission status and can only be set to END which
denotes the data transmission finishes.
 <binary_block_data> denotes the binary data to be downloaded. The data length
ranges from 4Bytes (2pt) to 32kBytes (16kpts). <binary_block_data> is a binary
data block starts with #. For example, #516384 binary data; the number 5
behind # denotes that the data length information (16384) occupies 5 characters.
16384 denotes the number of bytes of the binary data. As each waveform point
corresponds to two bytes of binary number (the range is from 0000 to 3FFF; 0000
and 3FFF correspond to the minimum and maximum values of the waveform
amplitude respectively), the number of bytes must be an even number.
 When END (data transmission complete indicator) is recieved, the instrument
switches to arbitrary waveform output automatically.

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
