Rigol DS1074Z Plus Programming Guide

RIGOL Chapter 2 Command System
2-150 MSO1000Z/DS1000Z Programming Guide
[:TRACe[<n>]]:DATA:DAC
Syntax
[:TRACe[<n>]]:DATA:DAC volatile,[<binary_block_data>|<value>,<value>,<value>...]
Description
Download binary data block or decimal waveform values to the volatile memory of the
specified signal source.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
1
<binary_block_data>
Refer to Explanation
<value>
Integer
0 to 16383
--
Explanation
 <binary_block_data> denotes the binary data to be downloaded. The data length is
from 4 Bytes (2 pts) to 32768 Bytes (16 kpts). <binary_block_data> is a binary data
block starts with #. For example, #516384 binary data; the number 5 behind #
denotes that the data length information (16384) occupies 5 characters. 16384
denotes the number of bytes of the binary data. As each waveform point
corresponds to two bytes of binary number (the range is from 0000 to 3FFF; 0000
and 3FFF correspond to the minimum and maximum values of the waveform
amplitude respectively), the number of bytes must be an even number.
 <value> denotes the decimal DAC values. 0 and 16383 correspond to the minimum
and maximum values of the waveform amplitude respectively. For example, when
the amplitude is 5Vpp and the offset is 0V
DC
, 0 corresponds to -2.5V and 16383
corresponds to 2.5V. The range of the number of waveform points is from 2pts to
16384pts. For example, 5 waveform point data are sent by the :DATA:DAC
volatile,0,16383,8192,0,16383 command.
 After sending this command, the specified signal source channel switches to volatile
waveform output automatically. While at the same time, the initial number of points
is modified. Users can edit the data downloaded using this command on the
instrument.

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
