Rigol DS1074Z Plus Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-75
:FUNCtion:WREPlay:FEND
Syntax
:FUNCtion:WREPlay:FEND <end>
:FUNCtion:WREPlay:FEND?
Description
Set or query the end frame of waveform playback.
Parameter
Name
Type
Range
Default
<end>
Integer
1 to the maximum number of frames
recorded
The maximum number
of frames recorded
Explanation
 Use the :FUNCtion:WRECord:FEND command to set the maximum number of
frames recorded.
 The end frame of waveform playback cannot be lower than the start frame of
waveform playback (:FUNCtion:WREPlay:FSTart).
 You can only set the end frame of waveform playback when a waveform is currently
recorded.
 You cannot set the end frame of waveform playback during the waveform recording
or playback process.
Return
Format
The query returns an integer.
Example
:FUNCtion:WREPlay:FEND 4096 /*Set the end frame of waveform playback to
4096*/
:FUNCtion:WREPlay:FEND? /*The query returns 4096*/
:FUNCtion:WREPlay:FMAX?
Syntax
:FUNCtion:WREPlay:FMAX?
Description
Query theb maximum number of frames can be played, namely the maximum number of
frames recorded.
Explanation
Use the :FUNCtion:WRECord:FEND command to set the maximum number of frames
recorded.
Return
Format
The query returns an integer.

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
