Rigol DS1074Z Plus Programming Guide

RIGOL Chapter 2 Command System
2-78 MSO1000Z/DS1000Z Programming Guide
:FUNCtion:WREPlay:FCURrent
Syntax
:FUNCtion:WREPlay:FCURrent <cur>
:FUNCtion:WREPlay:FCURrent?
Description
Set or query the current frame in waveform playback.
Parameter
Name
Type
Range
Default
<cur>
Integer
1 to the maximum number of
frames recorded
The maximum number
of frames recorded
Explanation
 Use the :FUNCtion:WRECord:FEND command to set the maximum number of
frames recorded.
 You can only set the current frame of waveform playback when a waveform is
currently recorded.
 You cannot set the current frame of waveform playback during the waveform
recording or playback process.
Return
Format
The query returns an integer.
Example
:FUNCtion:WREPlay:FCURrent 300 /*Set the current frame in waveform playback to
300*/
:FUNCtion:WREPlay:FCURrent? /*The query returns 300*/

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
