RIGOL Chapter 2 Command System
2-158 MSO1000Z/DS1000Z Programming Guide
:TRIGger Commands
The :TRIGger commands are used to set the trigger system of the oscilloscope.
Command List:
 :TRIGger:MODE
 :TRIGger:COUPling
 :TRIGger:STATus?
 :TRIGger:SWEep
 :TRIGger:HOLDoff
 :TRIGger:NREJect
 :TRIGger:POSition?
 :TRIGger:EDGe
 :TRIGger:PULSe
 :TRIGger:SLOPe
 :TRIGger:VIDeo
 :TRIGger:PATTern
 :TRIGger:DURATion
 :TRIGger:TIMeout
 :TRIGger:RUNT
 :TRIGger:WINDows
 :TRIGger:DELay
 :TRIGger:SHOLd
 :TRIGger:NEDGe
 :TRIGger:RS232
 :TRIGger:IIC
 :TRIGger:SPI
:TRIGger:MODE
Syntax
:TRIGger:MODE <mode>
:TRIGger:MODE?
Description
Select or query the trigger type.
Parameter
Name
Type
Range
Default
<mode>
Discrete
{EDGE|PULSe|RUNT|WIND|NEDG|SLOPe|VIDeo|
PATTern|DELay|TIMeout|DURation|SHOLd|
RS232|IIC|SPI}
EDGE
Return
Format
The query returns EDGE, PULS, RUNT, WIND, NEDG, SLOP, VID, PATT, DEL, TIM, DUR,
SHOL, RS232, IIC, or SPI.
Example
:TRIGger:MODE SLOPe /*Select slope trigger*/
:TRIGger:MODE? /*The query returns SLOP*/

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
