RIGOL Chapter 2 Command System
2-100 MSO1000Z/DS1000Z Programming Guide
:MATH:FILTer:W1
Syntax
:MATH:FILTer:W1 <freq1>
:MATH:FILTer:W1?
Description
Set or query the cutoff frequency (ωc1) of the low pass/high pass filter or cutoff
frequency 1 (ωc1) of the band pass/band stop filter. The default unit is Hz.
Parameter
Name
Type
Range
Default
<freq1>
Real
Refer to Explanation
Related to the filter type
LPASs|BPASs|BSTOP: 0.005 x screen
sample rate
HPASs: 0.1 x screen sample rate
Explanation
When the type of the filter is set to LPASs (low pass) or HPASs (high pass), you
need to set one cutoff frequency (ωc1). At this time, the range of <freq1> is from
(0.005 x screen sample rate) to (0.1 x screen sample rate), with a step of (0.005 x
screen sample rate). Wherein, Screen Sample Rate = 100/Horizontal Timebase.
When the type of the filter is set to BPASs (band pass) or BSTOP (band stop), you
need to set two cutoff frequencies. Send this command to set cutoff frequency 1
(ωc1); and send the :MATH:FILTer:W2 command to set cutoff frequency 2 (ωc2).
At this time, the range of <freq1> is from (0.005 x screen sample rate) to (0.095 x
screen sample rate), with a step of (0.005 x screen sample rate). Wherein, Screen
Sample Rate = 100/Horizontal Timebase.
Note: Cutoff frequency 1 (ωc1) must be lower than cutoff frequency 2 (ωc2).
Return
Format
The query returns the current cutoff frequency or cutoff frequency 1 in scientific
notation.
Example
:MATH:FILTer:W1 1000000 /*Set the cutoff frequency of the low pass filter to
1MHz*/
:MATH:FILTer:W1? /*The query returns 1.000000e+06*/
Related
Commands
:MATH:FILTer:TYPE
:TIMebase[:MAIN]:SCALe
