Rigol DS1074Z Plus Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-111
:MASK:CREate
Syntax
:MASK:CREate
Description
Create the pass/fail test mask using the current horizontal adjustment parameter and
vertical adjustment parameter.
Explanation
This command is valid only when the pass/fail test is enabled (:MASK:ENABle) and is not
in the run state (:MASK:OPERate).
Related
Commands
:MASK:X
:MASK:Y
:MASK:PASSed?
Syntax
:MASK:PASSed?
Description
Query the number of passed frames in the pass/fail test.
Return
Format
The query returns an integer.
:MASK:FAILed?
Syntax
:MASK:FAILed?
Description
Query the number of failed frames in the pass/fail test.
Return
Format
The query returns an integer.
:MASK:TOTal?
Syntax
:MASK:TOTal?
Description
Query the total number of frames in the pass/fail test.
Return
Format
The query returns an integer.
:MASK:RESet
Syntax
:MASK:RESet
Description
Reset the numbers of passed frames and failed frames as well as the total number of
frames in the pass/fail test to 0.
Related
Commands
:MASK:PASSed?
:MASK:FAILed?
:MASK:TOTal?

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
