Rigol DS1074Z Plus Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-125
:MEASure:ITEM
Syntax
:MEASure:ITEM <item>[,<src>[,<src>]]
:MEASure:ITEM? <item>[,<src>[,<src>]]
Description
Measure any waveform parameter of the specified source, or query the measurement
result of any waveform parameter of the specified source.
Parameter
Name
Type
Range
Default
<item>
Discrete
{VMAX|VMIN|VPP|VTOP|VBASe|VAMP|VAVG|
VRMS|OVERshoot|PREShoot|MARea|MPARea|
PERiod|FREQuency|RTIMe|FTIMe|PWIDth|
NWIDth|PDUTy|NDUTy|RDELay|FDELay|
RPHase|FPHase|TVMAX|TVMIN|PSLEWrate|
NSLEWrate|VUPper|VMID|VLOWer|VARIance|
PVRMS|PPULses|NPULses|PEDGes|NEDGes}
--
<src>
Discrete
Refer to Explanation
Explanation
 [,<src>[,<src>]] sets the source of the parameter to be measured.
 When <item> is PERiod, FREQuency, PWIDth, NWIDth, PDUTy, NDUTy, RDELay,
FDELay, RPHase, or FPHase, the range of <src> is
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D11|D12|D13|D14|D15|CHANnel1|CHAN
nel2|CHANnel3|CHANnel4|MATH}.
When <item> is any of other measurement parameters, the range of <src> is
{CHANnel1|CHANnel2|CHANnel3|CHANnel4|MATH}.
 If the parameter to be measured only needs a single source (VMAX, VMIN, VPP,
VTOP, VBASe, VAMP, VAVG, VRMS, OVERshoot, MARea, MPARea, PREShoot, PERiod,
FREQuency, RTIMe, FTIMe, PWIDth, NWIDth, PDUTy, NDUTy, TVMAX, TVMIN,
PSLEWrate, NSLEWrate, VUPper, VMID, VLOWer, VARIance, PVRMS, PPULses,
NPULses, PEDGes, and NEDGes), you only need to set a single source. If
[,<src>[,<src>]] is omitted, the source is the one selected by the :MEASure:SOURce
command by default.
 If the parameter to be measured needs two sources (RDELay, FDELay, RPHase, and
FPHase), the command needs to include two sources; otherwise, the command is
invalid. If [,<src>[,<src>]] is omitted, the sources are the ones selected by
the :MEASure:SETup:DSA and :MEASure:SETup:DSB or :MEASure:SETup:PSA
and :MEASure:SETup:PSB commands by default.
Return
Format
The query returns the measurement result in scientific notation.
Example
:MEASure:ITEM OVERshoot,CHANnel2 /*Enable the overshoot measurement of CH2*/
:MEASure:ITEM? OVERshoot,CHANnel2 /*The query returns 8.888889e-03*/

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
