Rigol DS1074Z Plus Programming Guide

RIGOL Chapter 2 Command System
2-118 MSO1000Z/DS1000Z Programming Guide
:MEASure:ADISplay
Syntax
:MEASure:ADISplay <bool>
:MEASure:ADISplay?
Description
Enable or disable the all measurement function, or query the status of the all
measurement function.
Parameter
Name
Type
Range
Default
<bool>
Bool
{{1|ON}|{0|OFF}}
0|OFF
Explanation
 The all measurement function can measure the following 29 parameters of the
source at the same time:
Voltage Parameters: Vmax, Vmin, Vpp, Vtop, Vbase, Vamp, Vupper, Vmid, Vlower,
Vavg, Vrms, Overshoot, Preshoot, Period Vrms, and Variance
Time Parameters: Period, Frequency, Rise Time, Fall Time, +Width, -Width, +Duty,
-Duty, tVmax, and tVmin
Other Parameters: +Rate, -Rate, Area, and Period Area.
 The all measurement function can measure CH1, CH2, CH3, CH4, and the MATH
channel at the same time. You can send the :MEASure:AMSource command to set
the source of the all measurement function.
Return
Format
The query returns 1 or 0.
Example
:MEASure:ADISplay ON /*Enable the all measurement function*/
:MEASure:ADISplay? /*The query returns 1*/
:MEASure:AMSource
Syntax
:MEASure:AMSource <src>[,<src>[,<src>[,<src>]]]
:MEASure:AMSource?
Description
Set or query the source(s) of the all measurement function.
Parameter
Name
Type
Range
Default
<src>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4|MATH}
CHANnel1
Return
Format
The query returns CHAN1, CHAN2, CHAN3, CHAN4, or MATH. Multiple sources are
separated by commas.
Example
:MEASure:AMSource CHANnel1,CHANnel3 /*Set the sources of the all measurement
function to CH1 and CH3*/
:MEASure:AMSource? /*The query returns CHAN1,CHAN3*/

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
