Rigol DS1074Z Plus Programming Guide

RIGOL Chapter 2 Command System
2-76 MSO1000Z/DS1000Z Programming Guide
:FUNCtion:WREPlay:FINTerval
Syntax
:FUNCtion:WREPlay:FINTerval <interval>
:FUNCtion:WREPlay:FINTerval?
Description
Set or query the time interval between frames in waveform playback. The default unit is
s.
Parameter
Name
Type
Range
Default
<interval>
Real
100ns to 10s
100ns
Explanation
 You can only set the time interval of waveform playback when a waveform is
currently recorded.
 You cannot set the time interval of waveform playback during the waveform
recording or playback process.
Return
Format
The query returns the current time interval in scientific notation.
Example
:FUNCtion:WREPlay:FINTerval 0.001 /*Set the time interval to 1ms*/
:FUNCtion:WREPlay:FINTerval? /*The query returns 1.000000e-03*/
:FUNCtion:WREPlay:MODE
Syntax
:FUNCtion:WREPlay:MODE <mode>
:FUNCtion:WREPlay:MODE?
Description
Set or query the waveform playback mode.
Parameter
Name
Type
Range
Default
<mode>
Discrete
{REPeat|SINGle}
SINGle
Explanation
 REPeat: cycle playback. Play from the start frame to the end frame and then repeat
until you stop it manually.
 SINGle: single playback. Play from the start frame to the end frame and then stop.
 You can only set the waveform playback mode when a waveform is currently
recorded.
 You cannot set the waveform playback mode during the waveform recording or
playback process.
Return
Format
The query returns REP or SING.
Example
:FUNCtion:WREPlay:MODE REPeat /*Set the waveform playback mode to cycle*/
:FUNCtion:WREPlay:MODE? /*The query returns REP*/

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
